The HB T series models are semi-automatic horizontal band saws for high-precision straight cuts in large workpieces made of steel, cast-iron and other metals. These machines are designed with a rigid, highly stable dual-column frame. The saw frame’s stroke cylinder is integrated in the frame.
- Dual-column construction
- Hydraulic vise with micro adjustment
- Extensive standard equipment
CUTTING CAPACITIES | |
---|---|
Cutting speed | 89 – 148 – 226 fpm |
Cutting capacity 0° (round) | 11 in |
Cutting capacity 0° (square) | 11 in |
Cutting capacity 0° (flat) (length x width) | 11 in x 11 in |
DRIVE CAPACITY | |
---|---|
Main motor rating | 4 Hp |
Motor rating hydraulic pump | 0.7 Hp |
Motor rating coolant pump | 0.1 Hp |
MEASURES AND WEIGHTS | |
---|---|
Blade dimensions | 137.99 in x 1.06 in x 0.04 in |
Overall dimensions (length x width x height) | 86 in x 52 in x 64 in |
Weight | 1529 lbs |
